Mid-level dual 4K output media player with full device management and support for multi-zone, HTML5 and ScalaScript content. Ideal for simple applications such as menu boards, schedules, directories, information boards and other displays with a lighter content load. With a slim form factor, an anodized aluminum housing and fanless design it fits into any digital signage location while staying protected from dirt and dust. Additional I/O features include Gigabit Ethernet, four USB 3.0 ports and RJ11 remote power switch.

  • OS: Windows 10 IoT Enterprise LTSC (“Windows 10 Embedded”) or Linux
  • CPU: AMD Ryzen Embedded R1505G
  • Graphics: AMD Radeon Vega 3
  • Video: Two HDMI 2.0 Output
  • Memory: 8GB DDR4-2400 SO-DIMM, dual-channel
  • Storage: 128GB NVME SSD (M.2 mPCIe 2280), Max 2TB
  • Network: Gigabit Ethernet RJ45
    2.4/5 GHz Dual-band WiFi (IEEE 802.11a/b/g/n/ac)
    Bluetooth v4.0 with BLE
    Optional: 2nd Ethernet NIC, 4G LTE
  • USB: Four USB 3.0 Type A ports
  • Serial: One DB9 Male
  • Housing: Anodized aluminum, fanless, K slot for secure mounting
  • Dimensions: 308mm (W) x 180mm (D) x 33mm (H) | 12.13" (W) x 7.09" (D) x 1.30" (H)
  • Weight: 2.98 kgs | 6.57 lbs
  • Operating Temp: 0° - +40° C | +32° - +104° F
  • Storage Temp: -15° - +65° C | +5° - +149° F
